Bottle opening device

【Patent name】 Bottle opener 【Applicant】 Huang Wenhua [Inventor] Huang Wenhua [The main applicant address] 745000 People's Hospital of Qingyang City, Gansu Province [Application Number] 200420115887.0
【 Application Date 】 2004.12.01
[Approved Announcement No.] 2758229
【 Validation announcement date 】 2006.02.15
[Main classification number] B67B7/44(2006.01)I
[Category Code] B67B7/44(2006.01)I
Sovereignty Item 1. Bottle opening device, characterized in that it includes a strip-shaped plate body (1), and a left end of the plate body (1) is provided with a V-shaped or U-shaped groove (2), and a plate body (1) There are circular alloy knives (3) located on the upper and lower sides of the groove (2), and each circular alloy knives (3) are located on the same surface of the plate body (1) and are respectively connected to the plate body. (1) The surfaces are parallel and the distance between the edges of the two round alloy knives (3) penetrating into the groove (2) corresponds to the bottle diameter of the medicine bottle, and the upper side of the left side of the plate body (1) is set There is a cotton swab receptacle (4) with at least one ampoule hole (5) on the underside of the left segment and a handle (6) on the right segment of the plate body (1).
[Instruction CD-ROM] D0607-2
【Abstracts】 A medicine bottle opening device includes a bar-shaped plate body, and a V-shaped or a ∪-shaped groove is provided at the left end of the plate body. The upper and lower sides of the plate body in the groove are respectively provided with round shapes. Alloy knife, each circular alloy knife is located on the same surface of the plate body and is respectively parallel to the surface of the plate body, and the distance between the edges of the two round alloy knives probed into the groove is corresponding to the bottle diameter of the medicine bottle. A cotton swab socket is arranged on the upper side of the left side of the plate body, and at least one ampoule hole is provided on the lower side of the left segment, and the right part of the plate body has a handle. In use, insert a plurality of antisepsis swabs into the socket of the cotton swab, first sterilize the bottleneck of the ampoules with a disinfectant swab, then turn the ampoules to cut the bottleneck between the two round alloy knives, and then place the ampoule bottle again. Insert the ampoule hole to break the bottleneck. The purpose is to provide a medicine bottle opening device which can improve the work efficiency of the medical staff and is convenient to use, and can avoid breaking the glass bottle by breaking the finger when the bottleneck of the bottleneck is broken, and preventing the glass chips from falling into the liquid medicine.
【 Agency 】 Beijing Shuangsou Intellectual Property Agency Co., Ltd. [Agent] Wu Zhongren Zuo Mingkun
